Laser Distance Meter Module
Light and small design for customer solutions as possible;
High shock resistance and wide operating temperature range;
Low power consumption conserves battery and thus extends operating times
Laser Distance Meter Module Introduction
In the relentless pursuit of excellence in distance measurement, our Laser Distance Meter Module sets a new standard. This cutting-edge device is meticulously engineered to deliver the precision and efficiency that professionals in various fields demand. With a user-centric design that prioritizes ease of use, our module is the go-to tool for architects, engineers, surveyors, and construction professionals who value accuracy and efficiency. Its lightweight, compact form factor, and advanced technology not only elevate the user experience but also ensure consistent and reliable measurements.
Elevate your work to the next level with our exceptionally reliable and high-performance Laser Distance Meter Module, designed to thrive in challenging work environments. Operating at a safe wavelength of 1535nm, this device offers measurement range from 15 to 3000 meters with an accuracy of ±1 meter, ensuring that your projects meet the highest standards of precision. Its minimal standby power consumption of ≤0.5W and the option for zero standby power usage make it an eco-friendly choice. Crafted from durable aluminum and featuring a sleek, compact design, our module is not just a standalone measurement tool but also an ideal component for products requiring medium and short-range distance measurement capabilities.
Technical Parameters
|
Items |
Index |
|
|
Laser wavelength |
1535nm |
|
|
Maximum range (m) |
Large target |
5500 |
|
|
Vehicle（2.3m×4.6m） |
3000 |
|
|
Human（0.5m×1.7m） |
2200 |
|
Minimum range (m) |
15 |
|
|
Ranging accuracy (m) |
±1 |
|
|
Size (L×W×H) (mm) |
≤50×36.5×24 |
|
|
Weight (g) |
≤58 |
|
|
Ranging frequency (Hz) |
Single time、1、5 |
|
|
Precision ratio |
≥98% |
|
|
False alarm rate |
≤1% |
|
|
Multiple target detection (pc) |
2 |
|
|
Communication port |
RS422/TTL |
|
|
Supply voltage（V） |
10～14 |
|
|
Standby power consumption（W） |
≤0.5, power off to achieve zero stand-by power consumption |
|
|
Operating temperature |
-40～+60 |
|
Working Principle
Laser Beam Emission: The module emits a laser beam that is directed towards the target.
Time of Flight Calculation: The time taken for the laser beam to travel to the target and back is measured.
Distance Computation: Using the known speed of light, the module calculates the distance based on the time of flight.
Data Processing: The raw data is processed to enhance accuracy and ensure reliable results.
Output Signal Generation: The final distance measurement is transmitted as an output signal, compatible with various devices.
Technical Advantages
Non-contact Measurement: Eliminates the need for physical contact, reducing the risk of measurement errors.
Speed of Light Technology: Utilizes the constant speed of light for quick and accurate distance calculations.
Low Power Consumption: Operates on a 3.7V to 5V DC power supply, making it energy efficient and suitable for extended use.
Wide Operating Temperature Range: Functions effectively in a variety of climates, ensuring consistent performance.
High Integration: Integrates multiple functionalities into a single module, simplifying the measurement process.
Application Fields
Construction and Architecture: Used for measuring distances and heights in building projects.
Surveying and Mapping: Employed in land and property surveys for accurate measurements.
Industrial Automation: Facilitates robotic guidance and obstacle detection in manufacturing environments.
Agricultural Technology: Assists in precision farming and crop analysis.
Research and Development: Supports scientific experiments and data collection.
Operation and Maintenance
Power On: Connect the module to a power source within the specified voltage range and switch on.
Initial Calibration: Perform calibration to ensure accurate measurements.
Measurement Process: Aim the module at the target and press the measure button to obtain the distance.
Data Reading: Read the distance from the display or through the communication interface.
Regular Maintenance: Check for dirt or damage and clean the module as necessary to maintain optimal performance.
Quality Control and Safety Standards
ISO Certification: Adheres to international quality management standards, ensuring product reliability.
Safety Compliance: Meets global safety regulations for laser equipment, safeguarding user safety.
Reliability Testing: Undergoes extensive testing to guarantee consistent performance.
Environmental Testing: Tested in various conditions to ensure functionality across different environments.
Traceability: Each module is traceable for quality assurance and customer satisfaction.
Why Choose Us?
Hainan Yiyang Technology is your go-to solution for high-quality Laser Distance Meter Modules. Our strengths include:
Experience: Decades of expertise in the manufacturing and supply of laser measurement devices.
Innovation: A commitment to developing state-of-the-art, independently researched and developed products.
Customization: Offering tailored solutions to meet the unique needs of our clients.
Quality Assurance: Rigorous testing and adherence to the highest quality standards.
Customer Service: Providing exceptional after-sales support to ensure customer satisfaction.
